CIJ Inkjet Printer VIDJET1580
Designed for production speed improvement
CIJ Inkjet Printer VIDJET1580
Designed for production speed improvement
- High-speed small character printing
- 10-inch color touchscreen, movable design
- 40–70 μm nozzle options
- High Speed, Standard & High Quality modes
- Prints numbers, characters, QR codes, barcodes, shifts and graphics
Built around the application.
The F650 high-speed small character continuous inkjet printer is designed for production speed improvement. It delivers clear codes on bottles, cans and boxes moving through fast food and beverage packaging lines.
High-speed CIJ inkjet printer F650 for fast food and beverage packaging lines. 10-inch movable touchscreen, 34-dot matrix, 40–70 μm nozzles. Get a free quote from WDOTMARK.
Specifications
- Printing lines
- 1 line (34-dot matrix), 4 lines (7×5 dot matrix)
- Nozzle options
- 40 μm, 50 μm, 60 μm, 70 μm
- Printing distance
- 3–10 mm (40 μm), 5–25 mm (50 μm), 5–40 mm (60/70 μm)
- Printing modes
- High Speed, Standard, High Quality
- Ink compatibility
- Dye-based ink
- Umbilical
- Length 2700 mm, diameter 21 mm, bending radius 150 mm
Where this model is used
Common problems this machine solves
Codes need to stay readable on food & beverage lines, high-speed packaging lines, bottles, cans
This machine is built for marking on Food & Beverage Lines, High-Speed Packaging Lines, Bottles, Cans. We match the ink, ribbon or laser source to your material so codes stay durable and readable.
The production line runs faster than the coder
Rated for Printing modes:High Speed, Standard, High Quality.
Frequent stops for cleaning or consumable changes
10-inch color touchscreen, movable design.
Frequently asked questions
How does continuous inkjet (CIJ) printing work?
CIJ jets a continuous stream of ink that breaks into droplets, which are electrically deflected onto the product. It is non-contact and uses ink plus a small amount of solvent (make-up).
What is CIJ best suited for?
High-speed lines and curved or uneven surfaces such as bottles, cans, cables and pipes. It prints multiple lines of text, dates, batch codes, barcodes and QR codes.
How many lines and what print height?
Per the specification: Printing lines:1 line (34-dot matrix), 4 lines (7×5 dot matrix). Confirm the exact height for your layout before ordering.
Dye ink or pigment ink — which do I need?
Dye-based ink suits everyday coding, while pigment-based ink gives high-contrast marks — including white ink — on dark or coloured surfaces.
How do I maintain it and prevent clogs?
Use the auto-clean cycle, keep fresh, well-mixed ink, and follow the recommended service intervals. Regular solvent top-up keeps viscosity stable and print quality consistent.
Is the machine certified?
Yes — WDOTMARK CIJ printers are CE and RoHS certified. Contact us if you need the certificates for your region.
How do I get a quote or a sample test?
Send your material, mark content and line speed through the inquiry form. We will confirm the configuration, test on your sample and provide a quote.
Discuss this product with WDOTMARK.
Share product photos, material details, marking content and production information for review.
